ZEEKR 7X

ZEEKR 7X Full Official Technical Configuration Specifications

Original factory complete parameters for ZEEKR 7X mid-size 5-door 5-seater pure electric family SUV, built on advanced SEA exclusive pure electric architecture, equipped with two high-voltage platforms: 800V and 900V ultra-fast charging. Two battery solutions: 75kWh second-gen Golden Brick lithium iron phosphate battery and 103kWh Qilin high-density ternary lithium battery, supporting 10%-80% ultra-fast charging within 10-11 minutes. Three power versions: 75kWh rear-wheel drive standard range, 103kWh rear-wheel drive long range, and 103kWh dual-motor all-wheel drive performance flagship. Max total system power reaches 585kW, official 0-100km/h acceleration as low as 2.98 seconds. All models adopt front double ball-joint MacPherson + rear five-link full independent suspension, optional ZEEKR Magic Carpet closed air suspension with continuous damping adjustment. Equipped with Qualcomm 8295 flagship cockpit chip, LiDAR-sensing L2++ full-scenario intelligent driving system, standard 7-airbag passive safety and floating large central control screen. All technical data is fully prepared for global overseas mid-size pure electric family SUV wholesale and export business by Sasa Trading Co., Ltd.

1. Exterior Body & Overall Dimension Parameters (All Versions Unified)

Specification Item	Official Standard Parameter
Vehicle Classification	Mid-size Pure Electric 5-door 5-seater Family SUV (RWD / Dual-Motor AWD)
Overall Length × Width × Height	4825 mm × 1930 mm × 1666 mm (RWD) / 4825 mm × 1930 mm × 1656 mm (AWD)
Wheelbase	2925 mm Ultra-spacious Passenger Wheelbase
Front Track / Rear Track	1652 mm / 1668 mm
Curb Weight Range	2280 kg (75kWh RWD) / 2410 kg (103kWh RWD) / 2560 kg (103kWh AWD)
Front Frunk Storage Volume	78 Liters Electric Front Cargo Trunk
Rear Trunk Luggage Volume	625 Liters (Seats Upright) / 1480 Liters (Rear Seats Fully Folded Flat)
Minimum Turning Radius	5.7 m Balanced Urban Maneuver & Parking Performance
Maximum Electronically Limited Top Speed	240 km/h (RWD) / 255 km/h (AWD Performance)
Standard Wheel & Tire Size (RWD Trims)	20-inch Multi-spoke Alloy Wheels with 255/50 R20 Silent Comfort All-season Tires
AWD Flagship Wheel Tire Size	20-inch Two-tone Sport Forged Alloy Wheels with 255/50 R20 High-grip Performance Tires
Magic Carpet Air Suspension Adjustable Ground Clearance	140 mm - 230 mm Multi-mode Height Adjustment (Optional Package)

2. Pure Electric Powertrain & Dynamic Performance Specifications

Performance Item	75kWh RWD 620km CLTC Standard Version	103kWh RWD 802km CLTC Long Range Version	103kWh Dual-Motor AWD 715km CLTC Performance Flagship Version
Drive Layout	Rear Single Permanent Magnet Synchronous Motor Rear-Wheel Drive (RWD)	Rear Single High-efficiency Permanent Magnet Synchronous Motor RWD	Front Asynchronous Motor + Rear Permanent Magnet Dual-Motor All-Wheel Drive (AWD)
Motor Peak Output Power & Torque	Rear motor: 370 kW / 535 N·m	Rear motor: 370 kW / 535 N·m	Combined total power: 585 kW / Total torque: 812 N·m
Transmission Type	8-in-one Integrated Oil-cooled Intelligent Electric Drive, Single-speed Fixed Ratio Reducer	Upgraded 8-in-one High-efficiency Oil-cooled Electric Drive Assembly	Dual Independent Oil-cooled Front & Rear High-performance Drive System
Battery Type & High Voltage Platform	2nd-gen Golden Brick LFP Battery, Native 800V Ultra-high Voltage Liquid Cooling Heat Pump Platform	High-density Qilin Ternary Lithium Battery, Native 900V Ultra-high Voltage Flash Charging Platform	Top-tier Qilin Ternary Lithium Battery, 900V Hyper Flash Liquid Cooling Charging Architecture
Battery Rated Capacity	75.0 kWh	103.0 kWh	103.0 kWh
CLTC Comprehensive Pure Electric Range	620 km Standard Long Range	802 km Ultra Long Pure EV Range	715 km Balanced Performance Pure EV Range
Peak DC Flash Fast Charging Power	450 kW Ultra-high Power DC Fast Charge	500 kW Hyper Flash Charging	500 kW Hyper Flash Charging
10% - 80% SOC DC Fast Charging Time	Within 11 Minutes	Within 10 Minutes	Within 10 Minutes
11kW AC On-board Slow Charging Full Time (0-100%)	Approx. 10.7 Hours	Approx. 14.7 Hours	Approx. 14.7 Hours
WLTC Comprehensive Power Consumption	13.9 kWh / 100km Low Daily Energy Consumption	13.9 kWh / 100km Ultra Low Energy Consumption	15.6 kWh / 100km Performance Comprehensive Power Consumption
Official 0-100km/h Acceleration Time	5.4 Seconds Daily Comfort Fast Acceleration	5.1 Seconds Comfort High-speed Acceleration	2.98 Seconds Flagship Top-tier Performance Acceleration
Full Suspension Standard Configuration	● Standard Front Double Ball-joint MacPherson Independent Suspension + Rear Five-link Independent Suspension, Fixed Damping Comfort Tuning; Optional Magic Carpet Closed Air Suspension Package	● Standard Full Independent Suspension, Optimized Long-range Comfort Calibration; Optional Magic Carpet Air Suspension with Continuous Damping Adjustment	● Standard Full Independent Suspension, Sport Chassis Calibration; Magic Carpet Air Suspension Optional Flagship Exclusive Package
External V2L Vehicle To Load Discharge Function	● Standard 2.2kW Outdoor Mobile Power V2L External Power Output Function	● Standard 6.0kW High-power Full Function V2L Camping Power Supply	● Standard 6.0kW Industrial-grade V2L Vehicle External Power Output
Driving Mode Presets	● Eco / Normal / Sport / Individual Custom Mode	● Eco / Normal / Sport / Snow / Individual Custom Mode	● Eco / Normal / Sport Plus / Snow / Off-road / Performance Custom Mode

3. Exterior Standard Full Configuration (All Versions)

Exterior Feature Name	Full Range Standard Configuration Details
Front Lighting System	Full ZEEKR Stream Matrix LED Headlight Assembly, Seamless Closed EV Aerodynamic Front Grille, Split Horizontal Blade LED Daytime Running Light Strip, Automatic Light Sensor Activation, LED High Mount Third Brake Light, AGS Intelligent Active Air Intake Grille
Side Rearview Mirrors	Two-tone Body & Black Floating Roof Hidden Flush Electric Door Handle Design, Electric Adjustable & Auto-Folding Mirrors, Full Heating Defrost Function, Integrated LED Dynamic Sequential Turn Signal Indicators, Built-in 360° Panoramic Surround View Camera Modules
Rear Tailgate & Taillight Assembly	● Standard Hands-free Inductive Electric Power Liftgate with Anti-pinch & Height Memory, Full LED Coastline Through-type Combination Taillights, Sport Aerodynamic Rear Diffuser Bumper Package
Window & Glass Functions	Double-layer Acoustic Heat Insulated Front Windshield, Deep Privacy Tinted Rear Side Glass, Full Electric Front & Rear One-touch Up/Down Window Lifting, Heated Windshield Washer Nozzles
Premium Exterior Extra Equipment	Full Galvanized Anti-corrosion Vehicle Body, Low Wind Resistance Aerodynamic Family SUV Body, Black Plastic Wheel Arch Protective Trim, Standard Integrated Silver Roof Side Rails, Multiple Fashion Metallic, Matte & Two-tone Dual Roof Body Paint Color Options (Obsidian Black, Star Silver, Glacier White, Cloud Gray, Amethyst Purple)

4. Interior Cabin & Comfort Configuration (Standard 5-seat Layout)

Interior Item	Complete Configuration Description
Seat Upholstery Material	Base Trim: Wear-resistant Soft Fabric Seats; Mid & High Trim: Skin-friendly Premium Nappa Synthetic Leather Upholstery with Diamond Sport Stitching Decoration
Front Seat Adjustment	Base Version: Driver 6-way Manual Adjustment, Passenger 4-way Manual Adjustment; Mid & High Version: Driver 12-way Full Electric Adjustment with Lumbar Support & 3-position Memory Function
Second Row Seat Layout	60/40 Split Bench Seat, Multi-angle Slide & Backrest Adjustable, Independent Foldable Rear Armrest with Built-in Cup Holders
Seat Comfort Functions	Front Seat Heating standard on mid trims; Front Heating + Ventilation + Multi-mode Massage standard on flagship AWD high trims
Air Conditioning System	● Standard Dual Zone Intelligent Wide-temperature Heat Pump Air Conditioning System, Independent Air Outlets for Front & Second Rows, PM2.5 High-efficiency Cabin Air Purification Filter with Real-time Cabin Air Quality Monitoring Sensor
Sunroof Configuration	○ Optional Ultra-large Panoramic Electric Sunroof with UV & Heat Insulation Coating
Steering Wheel Specification	D-shaped Multi-function Leather Wrapped Sport Steering Wheel, Electronic Column Shift Lever Design, Physical Control Buttons for Audio Media, Cruise Control & Vehicle Function Quick Switch
Cabin Convenience Core Features	Smart Comfort Access Full Vehicle NFC Digital Key & Keyless Entry, One-touch Push Start Ignition, 50W Wireless Fast Qi Phone Charging Pad, Front & Rear Dual USB-C Fast Charging Ports, Front & Rear Cabin 12V Power Outlets, Multi-color Ambient Interior LED Lighting
Rear Seat Folding Function	60/40 Split-Folding Second Row, Fully Flat Cargo Floor After Full Folding for Large Item Loading

5. Intelligent Cockpit & Infotainment System (All Versions)

Intelligent Hardware Item	Official Technical Parameters
On-board Infotainment Computing Chip	Qualcomm Snapdragon 8295 Flagship High-performance Cockpit Chip
On-board Operating System	Latest Generation ZEEKR OS Intelligent Vehicle Interactive Operating System
Instrument Display	10.2-inch Full LCD Digital Instrument Cluster with Real-time Driving Power, Remaining Range & Safety Data Display
Central Control Touch Screen	15.4-inch Floating High-definition Central Control Touch Display, Built-in Global Online & Offline Navigation System, ONE ID Intelligent Account Synchronization
Head-up Display (HUD)	○ Optional Intelligent AR-HUD Wide Field Head-up Display for High Flagship Trims
AI Intelligent Voice Assistant	Dual-zone Independent Intelligent Voice Recognition Control, Ultra-fast wake-up response speed, supports full voice control for air conditioner, multimedia audio, navigation and all basic vehicle adjustment functions
Mobile Phone Interconnection Compatibility	Full Compatibility with Wireless Apple CarPlay, Wireless Android Auto, Bluetooth High-fidelity Audio Streaming & Hands-free Calling Function, NFC Digital Vehicle Key Support
Audio Speaker System	Standard 8-Speaker Hi-Fi Sound System, Premium 12-speaker Surround Audio System Optional for Flagship AWD Trims
Smart Connected Vehicle Core Functions	Full-time 4G Full-speed On-board Network Module, ZEEKR Mobile App Full Remote Vehicle Status Query & Remote Control, Complete Over-the-air OTA Full Vehicle System Online Upgrade Function, Built-in Front HD Full-view Driving Recorder Camera

6. Qianli Haohan L2++ Full-scenario Intelligent Driving Assistance Safety System

Safety Function Module	Standard Function Introduction
Perception Hardware (Mid & High Trims Standard)	Single High-precision Long-range LiDAR + Three-eye High Definition Front Camera + Multiple Millimeter Wave Radars, Total 27 Sensing Sensors, 6 Front + 4 Rear Ultrasonic Parking Radars, 360° Panoramic Transparent Chassis Surround View Camera System
Autonomous Driving Computing Chip	High-computing Autonomous Driving Chip, 500TOPS High Computing Power
Full-speed Adaptive Cruise Control ACC	Full speed range 0-240km/h Stop & Go function, intelligent vehicle following for highway cruising, urban traffic congestion and ramp entry/exit daily road scenarios
Highway NCA Navigation Cruise Assist	Automatic lane change, ramp entry & exit, speed adjustment based on navigation road limit speed, long-distance highway automatic driving assist with official safety guarantee
Lane Safety Assistance Suite	Lane Departure Warning LDW, Active Lane Keeping Assist LKA, Road Edge Departure Protection Function, Emergency Lane Evasion Assist
Multi-scenario Automatic Emergency Braking AEB	Forward & Reverse Full-range Active Emergency Braking System, accurate recognition of pedestrians, cyclists, motorcycles and static road obstacles, forward collision early warning reminder function
Blind Spot & Rear Traffic Safety	Blind Spot Monitoring BSM, Rear Cross Traffic Alert RCTA, Safe Door Exit Opening Warning Reminder Function, Rear Approaching Vehicle Early Warning System
Intelligent Full-scenario Parking Assistant Suite	360° Panoramic Surround View Monitor, Dynamic Real-time Parking Trajectory Guidelines, AVP Memory Automatic Valet Parking, Remote Mobile App Controlled Narrow Space Parking Assist Function
Traffic Sign Recognition	TSR Traffic Speed Sign Recognition & Real-time Vehicle Speed Reminder System
Full Chassis Brake Stability Control (All Trims Standard)	Ventilated Drilled Front Disc Brakes / Solid Ventilated Rear Disc Brakes, IPB Intelligent Brake System, ABS Anti-lock Braking System, EBD Electronic Brake Force Distribution, BA Brake Assist, ESP Electronic Stability Program, Real-time Direct TPMS Intelligent Tire Pressure Monitoring System, Electronic Auto Hold Parking Brake

7. Passive Crash Safety Configuration (All Versions Standard)

Safety Configuration Item	Standard Safety Details
Complete Airbag Protection Layout	● Standard Full 7-airbag Premium Protection System: Front Driver & Passenger Main Airbags, Front Side Airbags, Far-side Anti-collision Airbag, Full-length Front & Rear Integrated Curtain Side Airbags, Driver Knee Protection Airbag
Child Safety Protection System	Dual Standard ISOFIX Child Seat Mounting Anchors on Rear Outer Seats, Rear Child Safety Door Locks, Pre-tensioned Load Limiter 3-point Safety Belts equipped for all 5 seating positions
Body Crash Safety Architecture	CTB Integrated Battery-body High-rigidity Reinforced Cage Safety Cabin, Multi-horizontal & Multi-longitudinal high tensile steel & 2000MPa hot-formed ultra-high strength steel applied on key impact zones, Optimized Front & Rear Progressive Crumple Energy Absorption Zones, Reinforced Side Impact Door Anti-collision Beams, fully compliant with global mainstream five-star crash safety certification standards
Battery Safety Protection (LFP / Ternary)	Fully sealed IP68 waterproof reinforced steel battery tray housing shell, complete intelligent liquid cooling PTM 2.0 thermal management system, passed strict pin piercing crash impact, deep water immersion, extrusion and thermal runaway anti-fire safety certification tests exceeding international industry standard requirements
Full Vehicle Anti-theft Security System	Advanced Grade Electronic Drive Motor Immobilizer, Full Vehicle Anti-theft Alarm System with Interior Surveillance Function, Anti-towing Protection Lock, Encrypted Remote Central Locking System
Additional Passive Safety Design	Automatic Emergency Hazard Light Activation triggered during hard emergency braking, Whiplash Protection Optimized Front Seat Headrest Structure, Pedestrian-friendly Energy-absorbing Bonnet Design, Automatic High Voltage Power Cut-off Function activated immediately after collision impact
