ZEEKR 9X

ZEEKR 9X Full Official Technical Configuration Specifications

Original factory complete parameters for ZEEKR 9X flagship large luxury 5-door SUV, built on advanced SEA-S super electric architecture with native 900V ultra-high voltage super hybrid platform, adopting 2.0T high thermal efficiency super hybrid dedicated engine with 46%+ thermal efficiency. Two battery capacity options: 55kWh and 70kWh ternary lithium battery, supporting 6C ultra-fast charging, 20%-80% SOC charging only takes 9 minutes. Divided into dual-motor all-wheel drive Max/Ultra versions and triple-motor AWD Hyper flagship version, maximum system comprehensive power reaches 1030kW, official 0-100km/h acceleration as low as 3.1 seconds. Full series standard closed dual-chamber air suspension + dual-valve CCD electromagnetic shock absorbers, high-end models equipped with exclusive 48V active anti-roll bar intelligent digital chassis. Equipped with Qianli Haohan H7 autonomous driving system powered by NVIDIA Thor-U high-computing chip, full LiDAR multi-sensor perception hardware, optional 2+2 independent four-seat luxury layout, Naim premium surround audio. All technical data is fully prepared for global overseas large luxury flagship plug-in hybrid SUV wholesale and export business by Sasa Trading Co., Ltd.

1. Exterior Body & Overall Dimension Parameters (All Versions Unified)

Specification Item	Official Standard Parameter
Vehicle Classification	Full-size Luxury Plug-in Hybrid 5-door SUV (Dual-Motor AWD / Triple-Motor AWD)
Overall Length × Width × Height	5239 mm × 2029 mm × 1819 mm
Wheelbase	3169 mm Ultra-spacious Luxury Passenger Wheelbase
Front Track / Rear Track	1725 mm / 1740 mm
Curb Weight Range	2840 kg (55kWh Dual-Motor) / 2900-3100 kg (70kWh Triple-Motor Hyper)
Rear Trunk Luggage Volume	600 Liters (5-seat upright) / 1680 Liters (Rear Seats Fully Folded Flat)
Minimum Turning Radius	6.1 m Balanced Large-body Luxury Maneuver Performance
Maximum Electronically Limited Top Speed	240 km/h All Versions
Standard Wheel & Tire Size (Max/Ultra)	21-inch Multi-spoke Luxury Alloy Wheels with 265/45 R21 Silent Comfort Tires
Hyper Flagship Wheel Tire Size	22-inch Two-tone Forged Performance Alloy Wheels with 275/40 R22 Premium Low-rolling-resistance Tires
Maximum Adjustable Ground Clearance	288 mm Air Suspension Lifting Mode

2. Plug-in Hybrid Powertrain & Dynamic Performance Specifications

Performance Item	Max 55kWh Dual-Motor AWD Version	Ultra 70kWh Dual-Motor AWD Version	Hyper 70kWh Triple-Motor AWD Flagship Version
Drive Layout	Front + Rear Dual Permanent Magnet Motor All-Wheel Drive (AWD)	Front + Rear Dual Permanent Magnet Motor All-Wheel Drive (AWD)	Front Asynchronous + Dual Rear Permanent Magnet Triple-Motor All-Wheel Drive (AWD)
Hybrid Engine Parameter	2.0T Atkinson Cycle Super Hybrid Engine, Max Power 205kW / 279Ps, Thermal Efficiency 46%+	2.0T Atkinson Cycle Super Hybrid Engine, Max Power 205kW / 279Ps, Thermal Efficiency 46%+	2.0T Atkinson Cycle Super Hybrid Engine, Max Power 205kW / 279Ps, Thermal Efficiency 46%+
System Total Peak Power & Torque	Combined total power: 660kW / Total torque: 1280 N·m	Combined total power: 660kW / Total torque: 1280 N·m	Combined total power: 1030kW / Total torque: 1800 N·m
Transmission Type	SEA Super Hybrid Intelligent DHT Transmission	Upgraded SEA Super Hybrid Intelligent DHT Transmission	Flagship Triple-Motor Exclusive High-performance DHT Drive System
Battery Type & Capacity	Ternary Lithium High-voltage Battery, 55.1 kWh	Ternary Lithium Ultra-high Energy Battery, 70.0 kWh	Ternary Lithium Ultra-high Energy 6C Flash Charging Battery, 70.0 kWh
CLTC Pure Electric Comprehensive Range	300 km Pure EV Range	380 km Ultra Long Pure EV Range	355 km Balanced Performance Pure EV Range
Full Oil-Electric CLTC Comprehensive Range	1160 km Long Comprehensive Range	1250 km Ultra Long Comprehensive Range	1165 km Balanced Performance Comprehensive Range
6C Ultra-fast Charging Performance	20%-80% SOC within 9 Minutes (Support 900V High-voltage Charging Pile)	20%-80% SOC within 9 Minutes (Support 900V High-voltage Charging Pile)	20%-80% SOC within 9 Minutes (Hyper Exclusive Hyper Flash Charging Architecture)
Official WLTC Feed-in Fuel Consumption	5.2 L / 100km Ultra Low Feed-in Fuel Consumption	5.0 L / 100km Low Feed-in Fuel Consumption	5.5 L / 100km Performance Feed-in Fuel Consumption
Official 0-100km/h Acceleration Time	3.9 Seconds Daily Luxury Acceleration	3.9 Seconds Comfort High-speed Acceleration	3.1 Seconds Flagship Top-tier Performance Acceleration
Fuel Tank Capacity	75 Liters, Compatible with RON 92 Regular Gasoline	75 Liters, Compatible with RON 92 Regular Gasoline	75 Liters, Compatible with RON 92 Regular Gasoline
Full Chassis Suspension Configuration	● Standard Front Double Wishbone Independent Suspension + Rear Five-link Independent Suspension, Closed Dual-chamber Air Suspension + Dual-valve CCD Electromagnetic Shock Absorbers, Comfort Luxury Tuning	● Standard Full Independent Suspension + Air Suspension + CCD Dampers, Optional 48V Active Anti-roll Bar Package	● Standard Full Independent Suspension + Air Suspension + Dual-valve CCD Dampers + Exclusive 48V Active Anti-roll Bar as Standard, 10-mode All-terrain Intelligent Chassis Control
External V2L Vehicle To Load Discharge Function	● Standard 2.2kW Outdoor Mobile Power V2L External Power Output Function	● Standard 6.0kW High-power Full Function V2L Camping Power Supply	● Standard 6.0kW Industrial-grade V2L Vehicle External Power Output
Driving Mode Presets	● EV / HEV / Eco / Normal / Sport / Individual Custom Mode	● EV / HEV / Eco / Normal / Sport / Snow / Individual Custom Mode	● EV / HEV / Eco / Normal / Sport Plus / Snow / Off-road / Performance Custom Mode

3. Exterior Standard Full Configuration (All Versions)

Exterior Feature Name	Full Range Standard Configuration Details
Front Lighting System	Full ZEEKR Vertical Matrix LED Headlight Assembly, Vertical Waterfall Luxury Chrome Front Grille, Split Vertical LED Daytime Running Light Strip, Automatic Light Sensor Activation, LED High Mount Third Brake Light
Side Rearview Mirrors	Body Color Large-size Luxury Mirrors, Electric Adjustable & Auto-Folding Mirrors, Full Heating Defrost Function, Integrated LED Dynamic Sequential Turn Signal Indicators, Built-in 360° Surround View Camera Modules
Rear Tailgate & Taillight Assembly	● Standard Hands-free Inductive Electric Power Liftgate with Anti-pinch & Height Memory, Full LED Star Diamond Through-type Combination Taillights, Luxury Rear Diffuser Bumper Package
Window & Glass Functions	Double-layer Acoustic Heat Insulated Front Windshield, Deep Privacy Tinted Rear Side Glass, Full Electric Front & Rear One-touch Up/Down Window Lifting, Heated Windshield Washer Nozzles
Premium Exterior Extra Equipment	Full Galvanized Anti-corrosion Vehicle Body, Luxury Square Flagship SUV Body, Black Plastic Wheel Arch Protective Trim, Standard Integrated Silver Roof Side Rails, Multiple Luxury Metallic, Matte & Two-tone Dual Roof Body Paint Color Options (Obsidian Black, Star Silver, Cloud Gray, Glacier White, Amethyst Purple)

4. Interior Cabin & Comfort Configuration (5-seat Standard / 2+2 Four-seat Optional)

Interior Item	Complete Configuration Description
Seat Upholstery Material	All trims standard Skin-friendly Premium Nappa Full Leather Upholstery with Luxury Diamond Stitching Decoration, Flagship Hyper Version Optional Top-tier Full Aniline Leather
Front Seat Adjustment	All trims standard Driver 12-way Full Electric Adjustment with Lumbar Support & 3-position Memory Function, Passenger 10-way Electric Adjustment
Seat Comfort Functions	Front + Second Row Heating + Ventilation + Multi-mode Massage standard on all mid & high trims; Hyper flagship adds Zero-gravity Rotatable Independent Captain Chairs (2+2 four-seat package)
Air Conditioning System	● Standard Four-zone Independent Intelligent Wide-temperature Heat Pump Air Conditioning System, Independent Air Outlets for Each Row, PM2.5 High-efficiency Cabin Air Purification Filter with Real-time Cabin Air Quality Monitoring Sensor
Sunroof Configuration	○ Optional Ultra-large Panoramic Electric Sunroof with UV & Heat Insulation Coating, Starry Sky Light Top Optional for Hyper Flagship
Steering Wheel Specification	Multi-function Full Leather Wrapped Luxury Steering Wheel, Electronic Column Shift Lever Design, Physical Control Buttons for Audio Media, Cruise Control & Vehicle Function Quick Switch
Luxury Exclusive Cabin Features (Ultra/Hyper)	Electric Silent Suction Door, Second Row Foldable Luxury Business Table, Multi-color Starlight Ambient Interior LED Lighting, Independent Refrigerated Mini Fridge in Rear Armrest
Cabin Convenience Core Features	Smart Comfort Access Full Vehicle NFC Digital Key & Keyless Entry, One-touch Push Start Ignition, 50W Wireless Fast Qi Phone Charging Pad, Front & Rear Dual USB-C Fast Charging Ports, Front & Rear Cabin 12V Power Outlets, Over 40 Built-in Multi-scene Storage Compartments
Rear Seat Layout (Standard 5-seat)	60/40 Split-Folding Rear Bench Seat, Fully Flat Rear Floor After Folding, Multi-angle Adjustable Rear Seat Backrest for Expanded Cargo Loading Capacity

5. Intelligent Cockpit & Infotainment System (All Versions)

Intelligent Hardware Item	Official Technical Parameters
On-board Infotainment Chip	Dual Snapdragon 8295 High-performance Cockpit Computing Chip
On-board Operating System	Latest Generation ZEEKR OS Intelligent Vehicle Interactive Operating System
Instrument Display	10.2-inch Full LCD Digital Instrument Cluster with Real-time Driving Power, Remaining Range & Safety Data Display
Central Control Touch Screen	15.4-inch Ultra-wide Floating High-definition Central Control Touch Display, Built-in Global Online & Offline Navigation System, ONE ID Intelligent Account Synchronization
Head-up Display (HUD)	○ Optional Intelligent AR-HUD Wide Field Head-up Display for Ultra & Hyper Flagship Trims
AI Intelligent Voice Assistant	Dual-zone Independent Intelligent Voice Recognition Control, Ultra-fast wake-up response speed, supports full voice control for air conditioner, multimedia audio, navigation and all basic vehicle adjustment functions
Mobile Phone Interconnection Compatibility	Full Compatibility with Wireless Apple CarPlay, Wireless Android Auto, Bluetooth High-fidelity Audio Streaming & Hands-free Calling Function, NFC Digital Vehicle Key Support
Audio Speaker System	Standard 16-Speaker Hi-Fi Sound System; Ultra & Hyper Trims Standard 32-speaker Naim Premium Dolby Atmos Surround Audio System
Smart Connected Vehicle Core Functions	Full-time 4G Full-speed On-board Network Module, ZEEKR Mobile App Full Remote Vehicle Status Query & Remote Control, Complete Over-the-air OTA Full Vehicle System Online Upgrade Function, Built-in Front HD Full-view Driving Recorder Camera

6. Qianli Haohan H7 L2++ Full-scenario Intelligent Driving Assistance Safety System

Safety Function Module	Standard Function Introduction
Perception Hardware (All Mid & High Trims Standard)	Single High-precision Long-range LiDAR + Three-eye High Definition Front Camera + 5 Long-range Millimeter Wave Radars, Total 32 Sensing Sensors, 6 Front + 4 Rear Ultrasonic Parking Radars, 360° Panoramic Transparent Chassis Surround View Camera System
Autonomous Driving Computing Chip	NVIDIA DRIVE Thor-U High-computing Autonomous Driving Chip, 2000TOPS Ultra High Computing Power
Full-speed Adaptive Cruise Control ACC	Full speed range 0-240km/h Stop & Go function, intelligent vehicle following for highway cruising, urban traffic congestion and ramp entry/exit daily road scenarios
Highway NCA Navigation Cruise Assist	Automatic lane change, ramp entry & exit, speed adjustment based on navigation road limit speed, long-distance highway automatic driving assist with official safety guarantee
Urban NCA City Navigation Driving Assist	Automatic traffic light passing, narrow road U-turn, pedestrian avoidance, complex urban road full automatic driving function
Lane Safety Assistance Suite	Lane Departure Warning LDW, Active Lane Keeping Assist LKA, Road Edge Departure Protection Function, Emergency Lane Evasion Assist
Multi-scenario Automatic Emergency Braking AEB	Forward & Reverse Full-range Active Emergency Braking System, accurate recognition of pedestrians, cyclists, motorcycles and static road obstacles, forward collision early warning reminder function
Blind Spot & Rear Traffic Safety	Blind Spot Monitoring BSM, Rear Cross Traffic Alert RCTA, Safe Door Exit Opening Warning Reminder Function, Rear Approaching Vehicle Early Warning System
Intelligent Full-scenario Parking Assistant Suite	360° Panoramic Surround View Monitor, Dynamic Real-time Parking Trajectory Guidelines, AVP Memory Automatic Valet Parking, Remote Mobile App Controlled Narrow Space Parking Assist Function
Traffic Sign Recognition	TSR Traffic Speed Sign Recognition & Real-time Vehicle Speed Reminder System
Full Chassis Brake Stability Control (All Trims Standard)	Ventilated Drilled Front Disc Brakes / Solid Ventilated Rear Disc Brakes, IPB Intelligent Brake System, ABS Anti-lock Braking System, EBD Electronic Brake Force Distribution, BA Brake Assist, ESP Electronic Stability Program, Real-time Direct TPMS Intelligent Tire Pressure Monitoring System, Electronic Auto Hold Parking Brake

7. Passive Crash Safety Configuration (All Versions Standard)

Safety Configuration Item	Standard Safety Details
Complete Airbag Protection Layout	● Standard Full 6-airbag Premium Protection System: Front Driver & Passenger Main Airbags, Front Side Airbags, Full-length Front & Rear Integrated Curtain Side Airbags, Driver Knee Protection Airbag; Optional Rear Independent Side Airbags for Four-seat Version
Child Safety Protection System	Dual Standard ISOFIX Child Seat Mounting Anchors on Rear Outer Seats, Rear Child Safety Door Locks, Pre-tensioned Load Limiter 3-point Safety Belts equipped for all seating positions
Body Crash Safety Architecture	High-rigidity Reinforced Cage Safety Cabin, Multi-horizontal & Multi-longitudinal high tensile steel & 2000MPa hot-formed ultra-high strength steel applied on key impact zones, Integrated high-strength battery protection frame, Optimized Front & Rear Progressive Crumple Energy Absorption Zones, Reinforced Side Impact Door Anti-collision Beams, fully compliant with global mainstream five-star crash safety certification standards
Ternary Lithium Battery Safety Protection	Fully sealed IP68 waterproof reinforced steel battery tray housing shell, complete intelligent liquid cooling thermal management system, passed strict pin piercing crash impact, deep water immersion, extrusion and thermal runaway anti-fire safety certification tests exceeding international industry standard requirements
Full Vehicle Anti-theft Security System	Advanced Grade Electronic Drive Motor Immobilizer, Full Vehicle Anti-theft Alarm System with Interior Surveillance Function, Anti-towing Protection Lock, Encrypted Remote Central Locking System
Additional Passive Safety Design	Automatic Emergency Hazard Light Activation triggered during hard emergency braking, Whiplash Protection Optimized Front Seat Headrest Structure, Pedestrian-friendly Energy-absorbing Bonnet Design, Automatic High Voltage Power Cut-off Function activated immediately after collision impact
