Volkswagen Tharu XR 06

Volkswagen Tharu XR 06 Full Official Technical Configuration Specifications

Original factory complete parameters for Volkswagen Tharu XR 06 compact 5-door urban SUV, covering 1.5T EVO II turbo petrol and pure electric e-Tharu EV powertrain options. Prepared fully for global overseas export trade display.

1. Exterior Body & Overall Dimension Parameters

Specification Item	Official Standard Parameter
Vehicle Classification	Compact Urban 5-door 5-seater Family SUV
Overall Length	4458 mm
Overall Width	1841 mm
Overall Height	1632 mm
Wheelbase	2680 mm
Front Track / Rear Track	1582 mm / 1604 mm
Curb Weight Range	1325 kg (Petrol Version) / 1580 kg (Pure EV Version)
Fuel Tank Capacity (Petrol Model)	56.5 Liters
Luggage Volume (Rear Seats Upright)	445 Liters
Max Luggage Volume (Rear Seats Fully Folded)	1443 Liters
Standard Wheel Rim Size	17-inch Alloy Wheels with 225/55 R17 All-season Tires
Optional Wheel Rim Size	18-inch Black Sport Alloy Wheels
Minimum Turning Radius	5.7 m
Max Braked Towing Capacity	1500 kg

2. Powertrain & Dynamic Performance Specifications

Performance Item	1.5T EVO II Turbo FWD Petrol	e-Tharu Pure Electric Front Wheel Drive EV
Core Power Unit	EA211 1.5T EVO II Miller Cycle Turbocharged Inline 4-Cylinder Petrol Engine	Front Permanent Magnet Synchronous Drive Motor
Engine Displacement	1498 cc	Internal Combustion Engine Not Equipped
Maximum Output Power	118 kW / 160 HP @ 4150-6000 rpm	150 kW / 204 HP Peak Power
Maximum Peak Torque	250 N·m @ 1750-4000 rpm	290 N·m Instant Peak Torque
Transmission Type	7-speed DSG Dry Dual Clutch Automatic Transmission	Single-speed Electric Reduction Gearbox
Driving Layout	Front Wheel Drive (FWD)	Front Wheel Drive (FWD)
Battery Configuration (EV Model)	N/A	Lithium Iron Phosphate LFP Traction Battery Pack
CLTC Pure Electric Range	N/A	420 km
DC Fast Charging Speed (30%-80% SOC)	Not Supported	35 Minutes
WLTC Combined Fuel Consumption	5.99 L / 100km	N/A
Maximum Top Speed	198 km/h	150 km/h
0-100km/h Acceleration Time	9.7 Seconds	7.9 Seconds
Suspension Structure	Front MacPherson Independent Suspension + Rear Multi-link Independent Suspension	Front MacPherson Independent Suspension + Rear Multi-link Independent Suspension
Driving Mode Selection	● Eco / Comfort / Sport / Individual Modes	● Eco / Comfort / Sport / Regenerative Brake Modes

3. Exterior Standard Full Configuration

Exterior Feature Name	Full Range Standard Configuration Details
Front Lighting System	Full LED Through-type Daytime Running Light Strip, LED Projector Headlights, Automatic Light Activation, Height Automatic Adjustment, Rain Light Sensing Function
Side Rearview Mirrors	Body-colored Electric Adjustable & Auto-Folding Mirrors, Heating Function, Integrated LED Turn Signal Indicators
Rear Tailgate & Taillights	Manual Lift Tailgate (Hands-Free Electric Power Tailgate Optional), Full LED Combination Taillights, Dynamic Light Effect Taillight for High Trim
Window & Glass Functions	Heat Insulated Front Windshield, Rear Privacy Tinted Glass, Rain-Sensing Front Wipers, Heated Windshield Washer Nozzles, Rear Window Electric Defroster
Additional Exterior Accessories	Black Aluminum Roof Side Rails, Chrome Window Surround Trim, Sport Lower Body Surround, Compact Spare Tire, Full Galvanized Anti-Corrosion Body Structure

4. Interior Cabin & Comfort Configuration

Interior Item	Complete Configuration Description
Seat Upholstery Material	Base Grade: Premium Fabric Seats; Mid & High Trim: Vienna Synthetic Leather Upholstery
Front Seat Adjustment	Driver 10-way Electric Adjustment with Lumbar Support & 2-position Memory, Passenger 6-way Electric Adjustment on Mid and High Trims
Seat Comfort Functions	Heated Front Seats Standard on Mid Trims, Front Seat Ventilation Function Available for Top High-end Version
Air Conditioning System	Dual-Zone Automatic Climatronic Air Conditioning, Independent Rear Air Outlets, PM2.5 Activated Carbon Air Purification Filter
Sunroof	○ Optional Panoramic Electric Tilt & Slide Sunroof with Electric Sunshade
Steering Wheel	Leather Wrapped Multi-function Steering Wheel, Heating Function Optional, Shift Paddle Control for Automatic Transmission
In-car Convenience Features	KESSY Keyless Entry & Push Button Start, Wireless Qi Phone Charging Pad, Front & Rear USB-C Fast Charging Ports, Multi-color Ambient LED Interior Lighting, Frameless Auto-dimming Rearview Mirror, Multiple 12V Power Outlets
Rear Seat Layout	60/40 Split-Folding Rear Bench Seat, Rear Center Armrest with Dual Cup Holders

5. Intelligent Cockpit & Infotainment System

Intelligent Hardware Item	Official Technical Parameters
On-board Infotainment Platform	MIB Latest Generation Intelligent Infotainment System with High-speed Automotive Processor
Digital Instrument Cluster	10.25-inch Volkswagen Digital Cockpit Pro Full LCD Customizable Dashboard
Central Infotainment Screen	12-inch Floating Touch Control Display, Built-in Real-time Navigation System
Head-up Display HUD	○ Optional Head-Up Display System for Top Trim Models
Intelligent Voice Control	Multi-zone Independent Voice Recognition Assistant, Fast Response for air conditioner, multimedia and navigation control
Mobile Phone Connectivity	Full Compatibility with Wireless Apple CarPlay, Wireless Android Auto and Huawei HiCar, Bluetooth Hands-free Audio & Calling
Audio Speaker System	Standard 6-Speaker Sound System, Optional BEATS Premium Hi-Fi Surround Sound Audio System
Connected Vehicle Services	4G On-board Network, myVW Mobile App Remote Control, OTA Online System Upgrade, Emergency E-Call Service, Real-time Vehicle Status Remote Monitoring

6. L2 IQ.DRIVE ADAS Active Driving Assistance System

Safety Function Module	Standard Function Introduction
Perception Hardware	High Definition Front Camera, Long-range Millimeter Wave Radar, Full Set Front & Rear Ultrasonic Parking Sensors, 360° Surround Environmental Perception
Travel Assist Full-speed Cruise	Adaptive Cruise Control with Stop & Go Function, Intelligent Vehicle Following for Highway and Urban Congestion Roads
Lane Safety Assistance	Lane Assist Lane Keeping System, Lane Departure Warning, Emergency Lane Keeping Intervention
Front Assist Automatic Emergency Braking	Forward AEB Emergency Braking, Pedestrian & Cyclist Detection Protection, Forward Collision Warning System
Blind Spot & Rear Safety	Side Assist Blind Spot Monitoring System, Rear Cross Traffic Alert RCTA, Rear Approaching Vehicle Obstacle Warning
Parking Assistance System	360° Panoramic Surround View Camera, Dynamic Guideline Rear View Camera, Front & Rear Park Distance Control Parking Sensors
Driver Monitoring & Recognition	Driver Fatigue Detection System, TSR Traffic Sign Recognition & Automatic Speed Limit Recognition
Chassis Brake Stability Control	ABS Anti-lock Braking, EBD Electronic Brake Force Distribution, EBA Brake Assist, ESC Electronic Stability Control, Traction Control System, Real-time TPMS Tire Pressure Monitoring, Multi-Collision Automatic Secondary Brake System

7. Passive Crash Safety Configuration

Safety Configuration Item	Standard Safety Details
Full Airbag Layout	Complete 6-airbag Standard Layout: Front Driver & Passenger Airbags, Front Side Airbags, Full Length Front & Rear Curtain Airbags
Child Safety Protection	Rear Outer ISOFIX Child Seat Mounting Anchors, Rear Child Safety Door Locks, 3-Point Safety Belts for All 5 Seating Positions with Front Pretensioners
Body Crash Safety Structure	Rigid High-strength Safety Cage Cabin with 81.7% High-strength Steel Ratio, Front & Rear Controlled Crumple Energy Absorption Zones, Reinforced Side Impact Door Beams, Comply with Euro NCAP Five-star Crash Safety Standards
Battery Safety (EV Version)	Multi-layer Sealed Battery Protection Shell, Complete Intelligent Thermal Management System, Pass Nail Penetration, Extrusion and Open Flame Burning Safety Tests
Anti-Theft Security System	Electronic Engine Immobilizer, Full Vehicle Anti-theft Alarm with Interior Surveillance & Towing Protection, Remote Central Encrypted Locking System
Additional Passive Safety Design	Emergency Automatic Hazard Light Activation during Hard Braking, Whiplash Optimized Front Seat Backrest Design, Pedestrian Friendly Bonnet Crush Safety Structure, Automatic Power/Fuel Cut-off after Collision Impact
