Volkswagen Teramont

Volkswagen Teramont Full Official Technical Configuration Specifications

Original factory complete parameters for Volkswagen Teramont full-size large 7-seater family SUV, covering multiple powertrain options with Front-Wheel Drive and 4MOTION permanent all-wheel drive systems. Prepared fully for global overseas export trade display.

1. Exterior Body & Overall Dimension Parameters

Specification Item	Official Standard Parameter
Vehicle Classification	Full-size Large 5-door SUV, Optional 6-seater / Standard 7-seater Layout
Overall Length	5097 mm
Overall Width	1990 mm
Overall Height	1780 mm
Wheelbase	2980 mm
Front Track / Rear Track	1704 mm / 1719 mm
Curb Weight Range	1990 kg (FWD) / 2120 kg (4MOTION AWD)
Fuel Tank Capacity	70 Liters
Luggage Volume (7-seat upright)	583 Liters
Max Luggage Volume (Rear seats fully folded)	2741 Liters
Standard Wheel Rim Size	19-inch Alloy Wheels with 255/55 R19 Tires
Optional Wheel Rim Size	20-inch Sebring Alloy Wheels, 21-inch Suzuka R-Line Sport Wheels
Minimum Turning Radius	5.95 m
Max Braked Towing Capacity	2200 kg (FWD) / 2500 kg (4MOTION AWD)

2. Powertrain & Dynamic Performance Specifications

Performance Item	2.0L Low Power TSI FWD	2.0L High Power TSI FWD/AWD	3.6L FSI V6 Naturally Aspirated 4MOTION AWD
Engine Model	EA888-DYN 4-cylinder Turbocharged Inline Engine	EA888-DTJ 5th Gen Variable Turbo TSI Engine	3.6L V6 Naturally Aspirated FSI Petrol Engine
Engine Displacement	1984 cc	1984 cc	3597 cc
Maximum Output Power	162 kW / 220 HP @ 5000 rpm	200 kW / 272 HP @ 5500 rpm	206 kW / 280 HP @ 6200 rpm
Maximum Peak Torque	350 N·m @ 1500-4000 rpm	400 N·m @ 1700-4500 rpm	360 N·m @ 3200 rpm
Transmission System	7-speed Wet DSG Dual Clutch Automatic	DQ501 7-speed Wet DSG / 8-speed Tiptronic Automatic Optional	8-speed Tiptronic Automatic Transmission
Driving Layout	Front Wheel Drive (FWD)	FWD Optional / 4MOTION Permanent Full-Time All-Wheel Drive	Standard 4MOTION Active Control All-Wheel Drive
WLTC Combined Fuel Consumption	7.8 L / 100km	8.2 L / 100km (FWD) / 8.8 L / 100km (AWD)	10.2 L / 100km
Top Maximum Speed	200 km/h	210 km/h	215 km/h
0-100km/h Acceleration Time	9.2 Seconds	7.6 Seconds	8.3 Seconds
Suspension Structure	Front MacPherson Independent Suspension + Rear Multi-link Independent Suspension	Front MacPherson Independent Suspension + Rear Multi-link Independent Suspension	Front MacPherson Independent Suspension + Rear Multi-link Independent Suspension with Adaptive Damping Optional
Driving Mode Selection	● Eco / Comfort / Sport / Individual	● Eco / Comfort / Sport / Individual	● Eco / Comfort / Sport / Offroad / Snow / Individual Modes

3. Exterior Standard Full Configuration

Exterior Feature Name	Full Range Standard Configuration Details
Front Lighting System	Full LED IQ.Light Matrix Projector Headlights, LED Daytime Running Light Strip, Automatic Light On/Off, Height Automatic Adjustment, Dynamic Adaptive Turning Lights on High Trim
Side Rearview Mirrors	Body-colored Electric Adjustable & Auto-Folding Mirrors, Heating Function, Integrated LED Dynamic Turn Signal Lights, Side Blind Spot Camera
Rear Tailgate & Taillights	Hands-Free Easy Open Electric Power Tailgate with Anti-Pinch & Height Memory, Full LED Combination Taillights, Dynamic Sequential Turn Signals for High-end Versions
Window & Glass Functions	Heat Insulated Front Windshield, Rear Privacy Tinted Glass, Rain-Sensing Front Wipers, Heated Windshield Washer Nozzles, Rear Window Electric Defroster
Additional Exterior Accessories	Aluminum Roof Side Rails, Chrome Window Surround Trim, R-Line Sport Body Kit Optional, Compact Spare Tire, Full Galvanized Anti-Corrosion Body Structure, Lockable Wheel Bolts

4. Interior Cabin & Comfort Configuration

Interior Item	Complete Configuration Description
Seat Upholstery Material	Base Grade: Premium Fabric; Mid Trim: Vienna Synthetic Leather; Top Trim: Genuine Nappa Leather / Microfiber Suede R-Line Sport Seats
Front Seat Adjustment	Driver 12-way Electric Adjustment with 4-way Lumbar Support & 3-position Memory, Passenger 8-way Electric Adjustment on Mid & High Trims
Seat Comfort Functions	Front Seat Heating Standard, Front Seat Ventilation & 8-mode Massage Function, Second-row Outer Seat Heating for High-end Versions, Optional Captain Independent Second-row Chairs for 6-seat Layout
Air Conditioning System	3-Zone Independent Climatronic Automatic Climate Control System, Independent Rear Air Vents, PM2.5 Allergen Air Purification & Negative Ion Fresh Air System
Sunroof	● Standard Panoramic Electric Tilt & Slide Sunroof with Electric Sunshade
Steering Wheel	Full Leather Wrapped Multi-function Steering Wheel, Heating Function Standard on Mid Trims, Shift Paddle Control, Physical Off-road Shortcut Buttons
In-car Convenience Features	KESSY Keyless Entry & One-touch Push Button Start, Wireless Qi Fast Phone Charging Pad, Front & Rear Type-C USB-C Fast Charging Ports, 30-color Ambient LED Interior Lighting, Frameless Auto-dimming Rearview Mirror, Multiple 12V Power Outlets in Cabin & Trunk
Rear Seat Layout	Standard 40/20/40 Split-Folding Third-row Seats, Rear Center Armrest with Dual Cup Holders, Independent Rear Air Outlets for Second & Third Rows

5. Intelligent Cockpit & Infotainment System

Intelligent Hardware Item	Official Technical Parameters
On-board Core Chip	Qualcomm Snapdragon 8155 8-core Automotive Grade Intelligent Processing Chip
Digital Instrument Panel	10.25-inch Volkswagen Active Info Display Full LCD Digital Dashboard, Fully Customizable Driving Data Interface
Central Infotainment Touch Screen	12-inch Discover Media Floating Ultra-wide Touch Display, High Trim Equipped with Discover Pro Max Navigation System
Head-up Display HUD	○ Optional AR Augmented Reality Head-Up Display System for Top Trim Models
Intelligent Voice Assistant	Multi-zone Independent Voice Recognition Control, Continuous Dialogue Execution, Support Voice Control for Air Conditioner, Seats, Sunroof, Navigation and Multimedia
Mobile Phone Interconnection	Full Compatibility with Wireless Apple CarPlay, Wireless Android Auto and Huawei HiCar, Bluetooth Hands-free Calling & Audio Streaming
Premium Audio System	Standard 8-speaker Surround Sound System, Harman Kardon Premium 12-speaker Hi-Fi Audio System Optional for High-end Trims
Connected Vehicle Functions	5G On-board Network, Mobile App Remote Control, OTA Online Upgrade, Wi-Fi Hotspot, Emergency E-Call Service, Real-time Vehicle Status Remote Monitoring

6. L2+ IQ.DRIVE ADAS Active Driving Assistance System

Safety Function Module	Standard Function Introduction
Environmental Perception Hardware	High-definition Surround Cameras, Long-range Millimeter Wave Radar, Full Set Front & Rear Ultrasonic Parking Radars, Full 360-degree Surround Environmental Perception
Travel Assist Full-speed Cruise	Full-speed Adaptive Cruise Control with Stop & Go Function, Combined Lane Centering Assist for Highway and Urban Congestion Road Intelligent Vehicle Following
Lane Safety Protection System	Lane Departure Warning LDW, Lane Keep Assist LKA, Emergency Active Lane Intervention Correction
Front Assist Automatic Emergency Braking	Forward AEB Emergency Braking, Pedestrian & Cyclist Detection Protection, Forward Collision Early Warning System
Blind Spot & Rear Traffic Safety	Side Assist Blind Spot Monitoring System, Rear Cross Traffic Alert RCTA, Rear Approaching Vehicle Warning & Obstacle Detection
Intelligent Parking Vision System	360° Panoramic Area View Surround Camera, Dynamic Guideline Rear View Camera, Full Front & Rear Park Distance Control Parking Sensors
Driver Monitoring System	DMS Driver Fatigue Monitoring System, TSR Traffic Sign Recognition & Automatic Speed Limit Identification
Chassis Stability & Brake Control	ABS Anti-lock Braking System, EBD Electronic Brake Force Distribution, EBA Emergency Brake Assist, ESC Electronic Stability Control, Traction Control System, Real-time TPMS Tire Pressure Monitoring, Multi-Collision Automatic Secondary Brake System

7. Passive Crash Safety Configuration

Safety Configuration Item	Standard Safety Details
Full Airbag Safety Layout	Complete 9-airbag Full Protection System: Front Dual Driver & Passenger Airbags, Front Side Airbags, Rear Side Airbags, Full Three-row Length Curtain Airbags, Front Center Inter Airbag
Child Safety Protection	Three Groups of Standard ISOFIX Child Seat Fixed Anchors on Second Row, Rear Child Safety Door Locks, 3-Point Safety Belts for All 7 Seating Positions
Body Crash Safety Structure	High-rigidity Safety Cage Cabin, 82.3% High-strength Steel Body Ratio, 26.8% Hot Formed Ultra-high Strength Steel Application, Front & Rear Controlled Crumple Energy Absorption Zones, Reinforced Side Impact Door Beams
Vehicle Anti-Theft Security System	Electronic Engine Immobilizer, Full Vehicle Anti-theft Alarm with Interior Surveillance & Towing Protection, Remote Central Locking System with Anti-scan Encryption Key
Additional Passive Safety Design	Emergency Automatic Hazard Light Activation during Hard Braking, Whiplash Optimized Active Front Headrest Design, Pedestrian Friendly Bonnet Crush Energy-absorbing Safety Structure, Fuel Supply Automatic Cut-off after Collision Impact
